Genuine Gunsmith fit barrels..

+5
Dr.Don
Blsi2600
AllAces
Wobbley
Jerry Keefer
9 posters

Go down

Genuine Gunsmith fit barrels.. Empty Genuine Gunsmith fit barrels..

Post by Jerry Keefer 2/12/2016, 10:11 pm

True blanks, no chambers, upper or lower lugs.. These are going to be single upper lug barrels..for Bullseye  Interesting concept initiated by Chuck Warner.. We have been shooting a one lug 45 since Sept. 15
Genuine Gunsmith fit barrels.. IMG_2669_zps04pk2ozh
Genuine Gunsmith fit barrels.. IMG_2209_zpswjj5kewf


Last edited by Jerry Keefer on 2/12/2016, 10:29 pm; edited 2 times in total
Jerry Keefer
Jerry Keefer

Posts : 1001
Join date : 2012-01-03
Location : Maidens, VA

Back to top Go down

Genuine Gunsmith fit barrels.. Empty Re: Genuine Gunsmith fit barrels..

Post by Wobbley 2/12/2016, 10:14 pm

For what pistol?
Wobbley
Wobbley
Admin

Posts : 4789
Join date : 2015-02-13

Back to top Go down

Genuine Gunsmith fit barrels.. Empty Re: Genuine Gunsmith fit barrels..

Post by Jerry Keefer 2/12/2016, 10:18 pm

Wobbley wrote:For what pistol?
1911 in 45, 9mm and S&W 52/38
Jerry Keefer
Jerry Keefer

Posts : 1001
Join date : 2012-01-03
Location : Maidens, VA

Back to top Go down

Genuine Gunsmith fit barrels.. Empty Re: Genuine Gunsmith fit barrels..

Post by AllAces 2/13/2016, 12:34 am

What is the twist on the M52 barrel?
AllAces
AllAces

Posts : 745
Join date : 2011-08-31

Back to top Go down

Genuine Gunsmith fit barrels.. Empty Re: Genuine Gunsmith fit barrels..

Post by Blsi2600 2/13/2016, 12:45 am

And the advantage is ??

Blsi2600

Posts : 158
Join date : 2013-03-27
Location : SW ILLINOIS

Back to top Go down

Genuine Gunsmith fit barrels.. Empty Re: Genuine Gunsmith fit barrels..

Post by Dr.Don 2/13/2016, 1:13 am

Jerry will have his own list of advantages.  But the main one to me would be you can have the twist you want, instead of the "standard" 16, which is not ideal in either 9mm or 38 IMHO.  This is of course way beyond what most of can do, even those of us with a bit of a machine shop.
Dr.Don
Dr.Don

Posts : 816
Join date : 2012-11-01
Location : Cedar Park, TX

Back to top Go down

Genuine Gunsmith fit barrels.. Empty Re: Genuine Gunsmith fit barrels..

Post by Dr.Don 2/13/2016, 1:16 am

Jerry, I have long assumed (perhaps in error) that a standard chrome moly barrel blank is not hard enough for lugs.  Is that not true?  Do you do any heat treatment to the lug areas?
Dr.Don
Dr.Don

Posts : 816
Join date : 2012-11-01
Location : Cedar Park, TX

Back to top Go down

Genuine Gunsmith fit barrels.. Empty Re: Genuine Gunsmith fit barrels..

Post by Jerry Keefer 2/13/2016, 3:01 am

AllAces wrote:What is the twist on the M52 barrel?
10 Twist
Jerry Keefer
Jerry Keefer

Posts : 1001
Join date : 2012-01-03
Location : Maidens, VA

Back to top Go down

Genuine Gunsmith fit barrels.. Empty Re: Genuine Gunsmith fit barrels..

Post by Jerry Keefer 2/13/2016, 3:12 am

Blsi2600 wrote:And the advantage is ??
Complete control of the machining process, which means, control of all C/L axis.. the barrel should be built from the bore C/L out.  The chamber can be single pointed to within several thousandths, and then reamed in a spider to attempt absolute concentricity. You can't do that with after market barrels..  The lugs, both upper and lower  can be controlled..All those will have one upper  lug.
Dr. Don, those complete 1911 blanks are in the mid 40s if I recall. The 52  is turned from a Douglas blank which carbide cutters were used.. It was hard on HS cutters..I am not sure of the RC on the Douglas but it is tough...   The lugs when fit tight between the breechface and slide lug really are not subjected to heavy wear, because nothing is moving under pressure.. 9 out of 10 1911s are running on the first lug.. I cut the lugs off my lady shooters 45 in Sept. and it has been running all winter like a Swiss watch.. ..


Last edited by Jerry Keefer on 2/15/2016, 3:22 pm; edited 1 time in total
Jerry Keefer
Jerry Keefer

Posts : 1001
Join date : 2012-01-03
Location : Maidens, VA

Back to top Go down

Genuine Gunsmith fit barrels.. Empty Re: Genuine Gunsmith fit barrels..

Post by troystaten 2/14/2016, 8:50 pm

Jerry you sure do some interesting and what looks like high quality work.  Thanks for showing us some of the projects you work on.

troystaten

Posts : 823
Join date : 2012-04-19

Back to top Go down

Genuine Gunsmith fit barrels.. Empty Re: Genuine Gunsmith fit barrels..

Post by Jerry Keefer 2/14/2016, 10:09 pm

Thank you Troy..
Here's a shot of the lugless 52 barrel.. It's coming along nicely..I enjoy the challenge of R&D
I am running out of time, so I stopped taking in work, so I could devote all my time to experimenting..SmileSmile

Genuine Gunsmith fit barrels.. IMG_2673%20-%20Copy_zpsx5hs8fao
Jerry Keefer
Jerry Keefer

Posts : 1001
Join date : 2012-01-03
Location : Maidens, VA

Back to top Go down

Genuine Gunsmith fit barrels.. Empty Re: Genuine Gunsmith fit barrels..

Post by troystaten 2/14/2016, 11:32 pm

A question for you, I know the model 52 is a really nice pistol with an excellent trigger but would a 1911 be a better platform because of the wide range of parts and frames available?

thanks

troystaten

Posts : 823
Join date : 2012-04-19

Back to top Go down

Genuine Gunsmith fit barrels.. Empty Re: Genuine Gunsmith fit barrels..

Post by Jerry Keefer 2/15/2016, 12:09 am

troystaten wrote:A question for you, I know the model 52 is a really nice pistol with an excellent trigger but would a 1911 be a better platform because of the wide range of parts and frames available?

thanks
Yes, absolutely..
Jerry Keefer
Jerry Keefer

Posts : 1001
Join date : 2012-01-03
Location : Maidens, VA

Back to top Go down

Genuine Gunsmith fit barrels.. Empty Re: Genuine Gunsmith fit barrels..

Post by JayhawkNavy02 2/15/2016, 2:36 am

Jerry, your a magician as always!   Can't wait to see the results!
JayhawkNavy02
JayhawkNavy02

Posts : 821
Join date : 2014-03-02
Age : 45
Location : San Diego

Back to top Go down

Genuine Gunsmith fit barrels.. Empty Re: Genuine Gunsmith fit barrels..

Post by Colt711 2/15/2016, 4:05 am

Jerry,
Lugless: 45 barrels. Is there a (lower) pressure limitation on these brls? If so should they be stamped something like "mid range ammo only"? Just wondering. Oh and the advantage? Smoother operaration? Better repeatability?
Thanks.

Ron Habegger

Colt711

Posts : 641
Join date : 2012-06-08
Age : 82
Location : Hudson, Florida

Back to top Go down

Genuine Gunsmith fit barrels.. Empty Re: Genuine Gunsmith fit barrels..

Post by Jerry Keefer 2/15/2016, 6:22 am

Most modern high pressure pistols are one lug. 357 Sig is one example. It doesn't get much more high
pessure than that.  Most 1911s are only fit to the first lug.  When fit tightly to the hood /breechface/upper slide lug the lock up is very strong.
Our proto type has many thousands of rounds thru it with no ill effects. Some one lug slides may appear on the future. That will allow a larger area for radial lock up and perhaps tighter groups.. We shall see..
Jerry Keefer
Jerry Keefer

Posts : 1001
Join date : 2012-01-03
Location : Maidens, VA

Back to top Go down

Genuine Gunsmith fit barrels.. Empty Re: Genuine Gunsmith fit barrels..

Post by HenryA 2/16/2016, 5:47 am

You could make a limited run of those - especially the 9mm 1911...
